Why Order CNC Turned Parts From Us
We’re committed to reducing friction at every stage, so you can be as delighted with the speed of your CNC Turned parts’ arrival as you are with their exceptional quality. Order now to receive your parts in as little as 5 days!
We offer over 60 production-grade materials including metal, plastic, and ceramic, and take great care to ensure the right material is used for every part.
Our standard CNC tolerance is +/- 0.127mm, and when you use our tolerance configurator, you can expect precision machining to be +/- 0.005mm.
We offer high-quality finishing processes for most CNC Turned parts; including anodizing, polishing and plating, heat treatment, powder coating, and more.
Our Maximum capabilities for
CNC turning
| Part size limitations | Metric units | Imperial units |
| Maximum part diameter | 508 mm | 20 inç |
| Maximum part length | 1066.8 mm | 42 inç |
| Maximum swing over the carriage | 355.6 mm | 14 inç |
| Maximum spindle through-hole | 50.8 mm | 2 inç |
Maximum Speed: 2000 RPM
Motor power: 750W
CNC Turning General Tolearances
From intricate medical and aerospace designs to complex industrial parts, our ISO 9001-certified company creates precision components with the highest level of accuracy. We utilize CNC turning lathes for complex machining projects requiring tight tolerance specifications up to ±0.005” – as close as a few thousandths of an inch! Our standards for metals follow ISO 2768-m while plastics adhere to requirements set by ISO 2768-c.
| Type | Tolerance |
| Linear Dimension | +/- 0.025 aa +/- 0.001 inç |
| Hole Diameters (not reamed) | +/- 0.025 aa +/- 0.001 inç |
| Shaft Diameters | +/- 0.025 aa +/- 0.001 inç |
| Part Size Limit | 950 * 550 * 480 mm 37.0 * 21.5 * 18.5 inç |
CNC Metals
Aluminum: Aluminum’s strength-to-weight ratio, affordability, and recyclability have made it widely used across industries worldwide.
Alloys: 6061-T6, 7075-T6, 2024, 5052, 6060, 5083, 2017, 6082
Finishing Options: Alodine, Anodizing Types II, III, III + PTFE, ENP, Media Blasting, Nickel Plating, Powder Coating, Tumble Polishing
Stainless steel: Stainless steel’s corrosion resistance and ductility make it ideal for long-term exposure to elements and easy shaping into different forms
Finishing Options: As machined, Bead Blasted, Polishing, Decorative Chrome Plating, Powder Coat, Nickel Plating, Gold Plating, Silver Plating
Alloys: SS303, Stainless Steel 304/304L, Stainless Steel 316/316L, Stainless Steel 17-4, Stainless Steel 416, etc.
Alloy Steel: Alloy steel is steel mixed with elements like manganese, nickel, and chromium to enhance its strength, hardness, corrosion resistance, and durability, tailored to meet specific application needs.
Alloy: AISI 1215, AISI 4140, AISI 4340, AISI 8620, AISI 4130
Finishing Option: Polishing, Plating, Painting, Powder Coating and etc.
Tool Steel: Tool steel is a type of high-carbon and high-alloy steel that is specifically designed to be used in the manufacture of cutting tools, dies, and molds. It is valued for its high hardness, wear resistance, and toughness, which make it suitable for applications where the tool is subjected to repeated impacts or stresses.
Alloy: A2 Tool Steel, D2 Tool Steel, O1 Tool Steel, S7 Tool Steel, M2 Tool Steel
Finishing Option: Bead/Sand Blast, Polishing, Plating, Painting, Powder Coating, Heat Treatment and etc.
Brass: Brass is an alloy of copper and zinc, especially metal material with more than 20% zinc content, which is the most commonly used metal material in cnc machining
Finishing Options: Nickel Plating, Bead Blasted, Gold Plating, Silver Plating
Alloy: C360, C260
Copper: Copper is a soft, malleable metal with excellent thermal and electrical conductivity, making it an essential material in many industries.
Grade: C10100, C11000, C12200, C14500, C17200
Finishing Option: Plating, Polishing
Titanium：Titanium has a low density and high strength, making it ideal for applications that require a strong yet lightweight material, such as aerospace, automotive, and biomedical industries. It is also highly resistant to corrosion and can withstand exposure to many chemicals and environments
Alloy: Ti-6Al-4V, Ti-6Al-2Sn-4Zr-2Mo, Ti-3Al-2.5V
Finishing Option: Polishing, Anodizing, Sandblasting, Chemical etching, Laser engraving and etc.
